CSX-252FAE24000000T,西铁城,24MHz,CSX-252F,CITIZEN晶振,2520振荡器

产品简介

CSX-252FAE24000000T,西铁城,24MHz,CSX-252F,CITIZEN晶振,2520振荡器

产品详情

CSX-252FAE24000000T,西铁城,24MHz,CSX-252F,CITIZEN晶振,2520振荡器

CITIZEN晶振也叫西铁城，是日本著名品牌，该晶振中物料编码为CSX-2520FAE24000000T的晶振，其频率是24MHz，电压为1.8V~3.3V，电流是7mA，频率稳定度为±50ppm，其输出方式是CMOS输出，工作温度为-40°C~85°C，型号是CSX-252F。这颗晶振的尺寸是2.5x 2.0mm，一般也叫2520振荡器，多应用于小型便携式设备/一般民用设备。小体积 2520晶振是小型化市场的福音,2520 因本身体积小型,厚度薄等特点,被使用在移动通讯,蓝牙设备等领域中, 康华尔电子 0755-27838351 生产的 2.5x2.0mm 贴片晶振产品具备高可靠性能,在恶劣环境中也能发挥正常工作,以可靠的产品质量在业界中小有名气

CSX-252FAE24000000T,西铁城,24MHz,CSX-252F,CITIZEN晶振,2520振荡器

品牌	CITIZEN
编码	CSX-252FAE24000000T
型号	CSX-252F
频率	24MHz
频率稳定度	±50ppm
电压	1.8V~3.3V
尺寸	2.5×2.0mm
工作温度	-40°C~85°C

CSX-252FAE24000000T,西铁城,24MHz,CSX-252F,CITIZEN晶振,2520振荡器

CSX-252F

更多相关晶振参考

原厂代码	品牌	型号	频率	输出	电压
CSX-252FAE24000000T	CITIZEN晶振	CSX-252F	24MHz	CMOS	1.8V~3.3V
CSX-252FAE30720000T	CITIZEN	CSX-252F	30.72MHz	CMOS	1.8V~3.3V
CSX-252FAE10000000T	CITIZEN	CSX-252F	10MHz	CMOS	1.8V~3.3V
CSX-252FAE35000000T	CITIZEN	CSX-252F	35MHz	CMOS	1.8V~3.3V
CSX-252FAP32768T	CITIZEN	CSX-252F	32.768kHz	CMOS	1.8V~3.3V
CSX-252FAE40000000T	CITIZEN	CSX-252F	40MHz	CMOS	1.8V~3.3V
CSX-252FAE33300000T	CITIZEN	CSX-252F	33.3MHz	CMOS	1.8V~3.3V
CSX-252FAE12000000T	CITIZEN	CSX-252F	12MHz	CMOS	1.8V~3.3V
CSX-252FAE20000000T	CITIZEN	CSX-252F	20MHz	CMOS	1.8V~3.3V
CSX-252FAE16934400T	CITIZEN	CSX-252F	16.9344MHz	CMOS	1.8V~3.3V
CSX-252FAE48000000T	CITIZEN	CSX-252F	48MHz	CMOS	1.8V~3.3V
CSX-252FAE33000000T	CITIZEN	CSX-252F	33MHz	CMOS	1.8V~3.3V
CSX-252FAE27000000T	CITIZEN	CSX-252F	27MHz	CMOS	1.8V~3.3V
CSX-252FAE6000000T	CITIZEN	CSX-252F	6MHz	CMOS	1.8V~3.3V
CSX-252FAE26000000T	CITIZEN	CSX-252F	26MHz	CMOS	1.8V~3.3V
CSX-252FAE13000000T	CITIZEN	CSX-252F	13MHz	CMOS	1.8V~3.3V
CSX-252FAE16000000T	CITIZEN	CSX-252F	16MHz	CMOS	1.8V~3.3V
CSX-252FAE24576000T	CITIZEN	CSX-252F	24.576MHz	CMOS	1.8V~3.3V
CSX-252FAE25000000T	CITIZEN	CSX-252F	25MHz	CMOS	1.8V~3.3V
CSX-252FAE50000000T	CITIZEN	CSX-252F	50MHz	CMOS	1.8V~3.3V
