美国松图SUNTSU晶振手表水晶有通孔或表面安装包装，有多种尺寸可供选择。手表晶体具有压电特性；它们在施加机械应力时产生电势。它们是目前使用的最常见的压电谐振器类型。
Suntsu松图晶振SWS112系列，是一款超小型晶振尺寸1.6x1.0mm陶瓷SMD 2垫手表水晶，频率：32.768K晶振，两脚贴片晶振，石英晶体谐振器，无源晶振，提供20ppm(公差)，超小型封装，磁带和卷轴，轻薄型，耐热及耐环境特点，应用于实时时钟，智能手机，电脑主板，钟表电子，测量仪器，无线蓝牙应用。手表水晶SWS11212D48-32.768K专用于实时时钟应用
手表水晶SWS11212D48-32.768K专用于实时时钟应用， 32.768K系列产品本身具有体积小,厚度薄,重量轻等特点,此音叉型石英晶体谐振器,小体积晶振产品本身具备优良的耐热性,耐环境特性,在办公自动化,家电领域,移动通信领域可发挥优良的电气特性,符合无铅标准,满足无铅焊接的回流温度曲线要求,金属外壳的石英晶振使得产品在封装时能发挥比陶瓷晶振外壳更好的耐冲击性能.
|
产品编码
|
包装尺寸
|
负载
|
频率稳定度
|
工作温度
|
时钟晶振
|
|
SWS11212D16-32.768K
|
1.6X1.0 CERAMIC SMD (2 PAD) Watch Crystal
|
12.5pF
|
±20ppm
|
-10℃ - +60℃
|
32.768K
|
|
SWS11212D48-32.768K
|
1.6X1.0 CERAMIC SMD (2 PAD) Watch Crystal
|
12.5pF
|
±20ppm
|
-40℃ - +85℃
|
32.768K
|
|
SWS1127D48-32.768K
|
1.6X1.0 CERAMIC SMD (2 PAD) Watch Crystal
|
7pF
|
±20ppm
|
-40℃ - +85℃
|
32.768K
|
|
SWS1129D16-32.768K
|
1.6X1.0 CERAMIC SMD (2 PAD) Watch Crystal
|
9pF
|
±20ppm
|
-10℃ - +60℃
|
32.768K
|
|
SWS1129D48-32.768K
|
1.6X1.0 CERAMIC SMD (2 PAD) Watch Crystal
|
9pF
|
±20ppm
|
-40℃ - +85℃
|
32.768K
|
|
SWS14412D48A-32.768K
|
10.4X4.06 PLASTIC SMD (4 PAD) Watch Crystal
|
12.5pF
|
±20ppm
|
-40℃ - +85℃
|
32.768K
|
|
SWS14412D48B-32.768K
|
10.4X4.06 PLASTIC SMD (4 PAD) Watch Crystal
|
12.5pF
|
±20ppm
|
-40℃ - +85℃
|
32.768K
|
|
SWS1446D48A-32.768K
|
10.4X4.06 PLASTIC SMD (4 PAD) Watch Crystal
|
6pF
|
±20ppm
|
-40℃ - +85℃
|
32.768K
|
|
SWS1446D48B-32.768K
|
10.4X4.06 PLASTIC SMD (4 PAD) Watch Crystal
|
6pF
|
±20ppm
|
-40℃ - +85℃
|
32.768K
|
|
SWS1449D48A-32.768K
|
10.4X4.06 PLASTIC SMD (4 PAD) Watch Crystal
|
9pF
|
±20ppm
|
-40℃ - +85℃
|
32.768K
|
|
SWS21212D48-32.768K
|
2.0X1.2 CERAMIC SMD (2 PAD) Watch Crystal
|
12.5pF
|
±20ppm
|
-40℃ - +85℃
|
32.768K
|
|
SWS2129F48-32.768K
|
2.0X1.2 CERAMIC SMD (2 PAD) Watch Crystal
|
9pF
|
±10ppm
|
-40℃ - +85℃
|
32.768K
|
|
SWS31212D16-32.768K
|
3.2X1.5 CERAMIC SMD (2 PAD) Watch Crystal
|
12.5pF
|
±20ppm
|
-10℃ - +60℃
|
32.768K
|
|
SWS31212D48-32.768K
|
3.2X1.5 CERAMIC SMD (2 PAD) Watch Crystal
|
12.5pF
|
±20ppm
|
-40℃ - +85℃
|
32.768K
|
|
SWS3126D16-32.768K
|
3.2X1.5 CERAMIC SMD (2 PAD) Watch Crystal
|
6pF
|
±20ppm
|
-10℃ - +60℃
|
32.768K
|
|
SWS3126D48-32.768K进口晶振
|
3.2X1.5 CERAMIC SMD (2 PAD) Watch Crystal
|
6pF
|
±20ppm
|
-40℃ - +85℃
|
32.768K
|
|
SWS3127D16-32.768K
|
3.2X1.5 CERAMIC SMD (2 PAD) Watch Crystal
|
7pF
|
±20ppm
|
-10℃ - +60℃
|
32.768K
|
|
SWS3127D48-32.768K
|
3.2X1.5 CERAMIC SMD (2 PAD) Watch Crystal
|
7pF
|
±20ppm
|
-40℃ - +85℃
|
32.768K
|
|
SWS3129D16-32.768K
|
3.2X1.5 CERAMIC SMD (2 PAD) Watch Crystal
|
9pF
|
±20ppm
|
-10℃ - +60℃
|
32.768K
|
|
SWS3129D48-32.768K
|
3.2X1.5 CERAMIC SMD (2 PAD) Watch Crystal
|
9pF
|
±20ppm
|
-40℃ - +85℃
|
32.768K
|
|
SWS41212D16-32.768K
|
4.1X1.5 CERAMIC SMD (2 PAD) Watch Crystal
|
12.5pF
|
±20ppm
|
-10℃ - +60℃
|
32.768K
|
|
SWS41212D48-32.768K
|
4.1X1.5 CERAMIC SMD (2 PAD) Watch Crystal
|
12.5pF
|
±20ppm
|
-40℃ - +85℃
|
32.768K
|
|
SWS51212D16-32.768K
|
4.9X1.8 CERAMIC SMD (2 PAD) Watch Crystal
|
12.5pF
|
±20ppm
|
-10℃ - +60℃
|
32.768K
|
|
SWS5127D16-32.768K
|
4.9X1.8 CERAMIC SMD (2 PAD) Watch Crystal
|
7pF
|
±20ppm
|
-10℃ - +60℃
|
32.768K
|
|
SWS5129D16-32.768K
|
4.9X1.8 CERAMIC SMD (2 PAD) Watch Crystal
|
9pF
|
±20ppm
|
-10℃ - +60℃
|
32.768K
|
|
SWS61412D48-32.768K
|
6.9X1.4 PLASTIC SMD (4 PAD) Watch Crystal
|
12.5pF
|
±20ppm
|
-40℃ - +85℃
|
32.768K
|
|
SWS83412D16-32.768K
|
8.0X3.8 PLASTIC SMD (4 PAD) Watch Crystal
|
12.5pF
|
±20ppm
|
-10℃ - +60℃
|
32.768K
|
|
SWS83412D48-32.768K
|
8.0X3.8 PLASTIC SMD (4 PAD) Watch Crystal
|
12.5pF
|
±20ppm
|
-40℃ - +85℃
|
32.768K
|
|
SWS8346D16-32.768K
|
8.0X3.8 PLASTIC SMD (4 PAD) Watch Crystal
|
6pF
|
±20ppm
|
-10℃ - +60℃
|
32.768K
|
|
SWS8346D48-32.768K
|
8.0X3.8 PLASTIC SMD (4 PAD) Watch Crystal
|
6pF
|
±20ppm
|
-40℃ - +85℃
|
32.768K
|
|
SWS8347D16-32.768K
|
8.0X3.8 PLASTIC SMD (4 PAD) Watch Crystal
|
7pF
|
±20ppm
|
-10℃ - +60℃
|
32.768K
|
|
SWS8347D48-32.768K
|
8.0X3.8 PLASTIC SMD (4 PAD) Watch Crystal
|
7pF
|
±20ppm
|
-40℃ - +85℃
|
32.768K
|
|
SWS8349D16-32.768K
|
8.0X3.8 PLASTIC SMD (4 PAD) Watch Crystal
|
9pF
|
±20ppm
|
-10℃ - +60℃
|
32.768K
|
|
SWS8349D48-32.768K
|
8.0X3.8 PLASTIC SMD (4 PAD) Watch Crystal
|
9pF
|
±20ppm
|
-40℃ - +85℃
|
32.768K
|
手表水晶SWS11212D48-32.768K专用于实时时钟应用，Suntsu晶振是一家专注于中端市场的电子产品制造商和经销商。我们的产品专长包括频率控制、互连、机电、天线和PCB。我们通过库存管理计划帮助客户制造更好的产品，节省时间、金钱，并改善现金流/交付周期。
