X1G004201001000编码TG-5006CE爱普生温补TCXO晶振,?GPS定位器专用晶振

GPS定位器专用晶振X1G004201001000编码TG-5006CE爱普生温补TCXO晶振

智能电动车GPS晶振H6203内部集成软启动以及过温保护电路,输出短路保护,限流保护等功能,提高系统可靠性.H6203具有低待机功耗、高效率、低纹波、优异的母线电压调整率和负载调整率等特性.

特征：内置150V高压mos 爱普生温补晶振宽输入电压范围：8V~120V 输出电压从5V到30V可调支持输出恒流支持输出12V/1A,5V/1.5A 高效率：可高达98% 工作频率：140KHz 低待机功耗内置过温保护内置软启动内置输出短路保护恒流（CC±5%）恒压（CV±5%）输出典型应用：车充、电池充电恒压源电动汽车、电动自行车、电瓶车led照明扭扭车、卡车GPS电源供电电动车仪器仪表供电

X1G004201001000编码TG-5006CE爱普生温补TCXO晶振,GPS定位器专用晶振

爱普生有源晶振编码	型号	频率	长X宽X高	输出波	电源电压	削顶正弦波;削峰正弦波;
X1G004131000400	TG-5006CJ	26.000000MHz	2.00x1.60x0.73mm	VC-TCXO~TCXO	1.700to1.900V	Clippedsinewave
X1G004131000600	TG-5006CJ	16.367667MHz	2.00x1.60x0.73mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004131000700	TG-5006CJ	16.368000MHz	2.00x1.60x0.73mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004131000800	TG-5006CJ	16.369000MHz	2.00x1.60x0.73mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004131000900	TG-5006CJ	19.200000MHz	2.00x1.60x0.73mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004131001000	TG-5006CJ	26.000000MHz	2.00x1.60x0.73mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004131001100	TG-5006CJ	38.400000MHz	2.00x1.60x0.73mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004131001300	TG-5006CJ	16.367667MHz	2.00x1.60x0.73mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004131001400	TG-5006CJ	16.368000MHz	2.00x1.60x0.73mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004131001500	TG-5006CJ	16.369000MHz	2.00x1.60x0.73mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004131001600	TG-5006CJ	19.200000MHz	2.00x1.60x0.73mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004131001700	TG-5006CJ	26.000000MHz	2.00x1.60x0.73mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004131001800	TG-5006CJ	38.400000MHz	2.00x1.60x0.73mm	VC-TCXO~TCXO	1.700to3.300V	Clippedsinewave
X1G004131002600	TG-5006CJ	40.000000MHz	2.00x1.60x0.73mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004131002900	TG-5006CJ	19.200000MHz	2.00x1.60x0.73mm	VC-TCXO~TCXO	2.600to3.000V	Clippedsinewave
X1G004131003100	TG-5006CJ	40.000000MHz	2.00x1.60x0.73mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004131003200	TG-5006CJ	26.635300MHz	2.00x1.60x0.73mm	VC-TCXO~TCXO	2.700to3.465V	Clippedsinewave
X1G004131003300	TG-5006CJ	28.974000MHz	2.00x1.60x0.73mm	VC-TCXO~TCXO	2.700to3.465V	Clippedsinewave
X1G004131003400	TG-5006CJ	26.000000MHz	2.00x1.60x0.73mm	VC-TCXO~TCXO	1.700to1.900V	Clippedsinewave
X1G004131003600	TG-5006CJ	26.000000MHz	2.00x1.60x0.73mm	VC-TCXO~TCXO	2.660to2.940V	Clippedsinewave
X1G004131003700	TG-5006CJ	19.200000MHz	2.00x1.60x0.73mm	VC-TCXO~TCXO	2.660to2.940V	Clippedsinewave
X1G004131003800	TG-5006CJ	26.000000MHz	2.00x1.60x0.73mm	VC-TCXO~TCXO	1.700to1.900V	Clippedsinewave
X1G004131004100	TG-5006CJ	40.000000MHz	2.00x1.60x0.73mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004131004200	TG-5006CJ	32.000000MHz	2.00x1.60x0.73mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004131004400	TG-5006CJ	24.576000MHz	2.00x1.60x0.73mm	VC-TCXO~TCXO	3.135to3.465V	Clippedsinewave
X1G004131004900	TG-5006CJ	26.000000MHz	2.00x1.60x0.73mm	VC-TCXO~TCXO	1.700to1.900V	Clippedsinewave
X1G004201000600	TG-5006CE	16.367667MHz	3.20x2.50x0.90mm	VC-TCXO~TCXO	1.700to1.900V	Clippedsinewave
X1G004201000800	TG-5006CE	16.369000MHz	3.20x2.50x0.90mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004201000900	TG-5006CE	19.200000MHz	3.20x2.50x0.90mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004201001000	TG-5006CE	26.000000MHz	3.20x2.50x0.90mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004201001300	TG-5006CE	16.367667MHz	3.20x2.50x0.90mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004201001700	TG-5006CE	26.000000MHz	3.20x2.50x0.90mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004201002000	TG-5006CE	26.000000MHz	3.20x2.50x0.90mm	VC-TCXO~TCXO	2.660to2.940V	Clippedsinewave
X1G004201002300	TG-5006CE	26.000000MHz	3.20x2.50x0.90mm	VC-TCXO~TCXO	1.700to3.465V	Clippedsinewave
X1G004201002500	TG-5006CE	32.000000MHz	3.20x2.50x0.90mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004201002600	TG-5006CE	26.000000MHz	3.20x2.50x0.90mm	VC-TCXO~TCXO	2.660to2.940V	Clippedsinewave
X1G004201003200	TG-5006CE	20.000000MHz	3.20x2.50x0.90mm	VC-TCXO~TCXO	3.135to3.465V	Clippedsinewave
X1G004201003300	TG-5006CE	25.000000MHz	3.20x2.50x0.90mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004201006200	TG-5006CE	32.000000MHz	3.20x2.50x0.90mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004211000100	TG-5006CG	26.000000MHz	2.50x2.00x0.80mm	VC-TCXO~TCXO	2.660to2.940V	Clippedsinewave
X1G004211000200	TG-5006CG	26.000000MHz	2.50x2.00x0.80mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004211000300	TG-5006CG	26.000000MHz	2.50x2.00x0.80mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004211000400	TG-5006CG	16.368000MHz	2.50x2.00x0.80mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004211000500	TG-5006CG	26.000000MHz	2.50x2.00x0.80mm	VC-TCXO~TCXO	1.700to1.900V	Clippedsinewave
X1G004211000600	TG-5006CG	16.367667MHz	2.50x2.00x0.80mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004211000800	TG-5006CG	16.369000MHz	2.50x2.00x0.80mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004211001100	TG-5006CG	38.400000MHz	2.50x2.00x0.80mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004211001500	TG-5006CG	16.369000MHz	2.50x2.00x0.80mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004211001600	TG-5006CG	19.200000MHz	2.50x2.00x0.80mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004211002700	TG-5006CG	30.000000MHz	2.50x2.00x0.80mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004211003100	TG-5006CG	24.000000MHz	2.50x2.00x0.80mm	VC-TCXO~TCXO	2.850to3.150V	Clippedsinewave
X1G004211003300	TG-5006CG	49.999800MHz	2.50x2.00x0.80mm	VC-TCXO~TCXO	1.700to3.465V	Clippedsinewave
X1G004211003400	TG-5006CG	26.000000MHz	2.50x2.00x0.80mm	VC-TCXO~TCXO	2.520to3.080V	Clippedsinewave
X1G004211003700	TG-5006CG	24.000000MHz	2.50x2.00x0.80mm	VC-TCXO~TCXO	1.700to3.465V	Clippedsinewave

智能电动车GPS定位器降压恒压IC8-120V转5V2A概述：H6203是支持宽电压输入的开关降压型DC-DC的控制器,内置150V-9A的高压mos,高输入电压可高达120V. H6203同时支持输出恒压和输出恒流功能CC/CV.通过设置CS电阻可设置输出过流值恒流值.爱普生晶振通过设置FB1、FB2引脚的分压电阻可设置输出电压值（恒压值）.H6203采用固定频率的PWM控制方式,典型开关频率为140KHz.轻载时会自动降低开关频率以获得高的转换效率.
