ATS-SM,ATS098SM-1,9.8304MHz,20PF,30PPM,-20~70℃,49SMD，美国CTS晶振公司,功能标准HC-49/US[通孔]和HC-49/US-SM[表面安装]包装稳定频率超过温度和驱动水平基础和第三泛音晶体频率范围3.2-64MHz频率容差，±30 ppm标准频率稳定性，±50ppm，50标准工作温度-20°C+70°标准，-40°C+85°C胶带和卷轴包装可用RoHS/绿色兼容[6/6]应用ATS/ATS-SM晶体系列提供了良好的长期稳定性和可靠性。优异的冲击性能使其适用于微处理器、电信、工业、消费电子和网络应用。
ATS-SM,ATS098SM-1,9.8304MHz,20PF,30PPM,-20~70℃,49SMD
|
PARAMETER
|
VALUE
|
|
Frequency Range
|
3.2 MHz to 64.0 MHz
|
|
Operating Mode
|
Fundamental or 3rd Overtone
|
|
Crystal Cut
|
AT-Cut
|
|
Frequency Tolerance @ +25°C
|
± 30 ppm Standard *
|
Frequency Stability Tolerance
(Operating Temperature Range, Referenced to 25°C Reading)
|
± 50 ppm Standard *
|
|
Operating Temperature Range
|
-20°C to +70°C *
-40°C to +85°C Available, See Ordering Information
|
|
Equivalent Series Resistance
|
See ESR Table
|
|
Load Capacitance or Resonance Mode
|
See Standard Part Numbers tables *
|
|
Shunt Capacitance (C0)
|
7.0 pF Maximum
|
|
Drive Level
|
100 µW Typical, 1,000 µW Maximum
|
|
Aging @ +25°C
|
±3 ppm/yr Typical, ±5 ppm/yr Maximum
|
|
Insulation Resistance
|
500 Ohms @ DC 100V
|
|
Storage Temperature Range
|
-40°C to +85°C
|
|
Reflow Condition, per JEDEC J-STD-020
|
+260°C Maximum, 10 Seconds Maximum
|
ATS-SM,ATS098SM-1,9.8304MHz,20PF,30PPM,-20~70℃,49SMD
|
CTS原厂编码
|
生产厂家
|
型号
|
Type 系列
|
频率
|
频率稳定度
|
频率偏差
|
负载电容
|
|
ATS049ASM-1
|
CTS-Frequency Controls
|
ATS-SM
|
MHz Crystal
|
4.9152MHz
|
±50ppm
|
±30ppm
|
Series
|
|
ATS08ASM-1E
|
CTS-Frequency Controls
|
ATS-SM
|
MHz Crystal
|
8MHz
|
±50ppm
|
±30ppm
|
20pF
|
|
ATS060SM-1E
|
CTS-Frequency Controls
|
ATS-SM
|
MHz Crystal
|
6MHz
|
±50ppm
|
±30ppm
|
20pF
|
|
ATS041CSM-1E
|
CTS-Frequency Controls
|
ATS-SM
|
MHz Crystal
|
4.194304MHz
|
±50ppm
|
±30ppm
|
12pF
|
|
ATS080SM-1
|
CTS-Frequency Controls
|
ATS-SM
|
MHz Crystal
|
8MHz
|
±50ppm
|
±30ppm
|
Series
|
|
ATS240SM-1
|
CTS-Frequency Controls
|
ATS-SM
|
MHz Crystal
|
24MHz
|
±50ppm
|
±30ppm
|
Series
|
|
ATS100SM-1
|
CTS-Frequency Controls
|
ATS-SM
|
MHz Crystal
|
10MHz
|
±50ppm
|
±30ppm
|
Series
|
|
ATS080SM-1E
|
CTS-Frequency Controls
|
ATS-SM
|
MHz Crystal
|
8MHz
|
±50ppm
|
±30ppm
|
Series
|
|
ATS12ASM-1E
|
CTS-Frequency Controls
|
ATS-SM
|
MHz Crystal
|
12MHz
|
±50ppm
|
±30ppm
|
20pF
|
|
ATS240BSM-1E
|
CTS-Frequency Controls
|
ATS-SM
|
MHz Crystal
|
24MHz
|
±50ppm
|
±30ppm
|
18pF
|
|
ATS08ASM-1
|
CTS-Frequency Controls
|
ATS-SM
|
MHz Crystal
|
8MHz
|
±50ppm
|
±30ppm
|
20pF
|
|
ATS036SM-1
|
CTS-Frequency Controls
|
ATS-SM
|
MHz Crystal
|
3.579545MHz
|
±50ppm
|
±30ppm
|
18pF
|
|
ATS160SM-1
|
CTS-Frequency Controls
|
ATS-SM
|
MHz Crystal
|
16MHz
|
±50ppm
|
±30ppm
|
Series
|
|
ATS200SM-1
|
CTS-Frequency Controls
|
ATS-SM
|
MHz Crystal
|
20MHz
|
±50ppm
|
±30ppm
|
Series
|
|
ATS049BSM-1
|
CTS-Frequency Controls
|
ATS-SM
|
MHz Crystal
|
4.9152MHz
|
±50ppm
|
±30ppm
|
18pF
|
|
ATS080BSM-1
|
CTS-Frequency Controls
|
ATS-SM
|
MHz Crystal
|
8MHz
|
±50ppm
|
±30ppm
|
18pF
|
|
ATS250BSM-1E
|
CTS-Frequency Controls
|
ATS-SM
|
MHz Crystal
|
25MHz
|
±50ppm
|
±30ppm
|
18pF
|
|
ATS060SM-1
|
CTS-Frequency Controls
|
ATS-SM
|
MHz Crystal
|
6MHz
|
±50ppm
|
±30ppm
|
20pF
|
|
ATS120SM-1
|
CTS-Frequency Controls
|
ATS-SM
|
MHz Crystal
|
12MHz
|
±50ppm
|
±30ppm
|
Series
|
|
ATS037BSM-1
|
CTS-Frequency Controls
|
ATS-SM
|
MHz Crystal
|
3.6864MHz
|
±50ppm
|
±30ppm
|
18pF
|
|
ATS120SM-1E
|
CTS-Frequency Controls
|
ATS-SM
|
MHz Crystal
|
12MHz
|
±50ppm
|
±30ppm
|
Series
|
